HELIX NEXT V TWO
Bridgeable 2-channel with V-AMP Link, Amplifier Control Panel and DirectDSP input
The perfect addition to powerful audio setups
The HELIX V TWO 2-channel amplifier uniquely combines audiophile sound aspirations with impressive output performance. Its wideband frequency response, excellent signal-to-noise ratio and ultra-low distortion ensure a sound quality that will satisfy even the most demanding music enthusiasts.
Thanks to its bridgeable speaker outputs, the amplifier offers flexible configuration options and delivers maximum output – whether in mono mode to drive high-performance subwoofers or in stereo configuration for powerful speaker systems. If you're looking for a compact powerhouse with audiophile DNA, here comes your ideal solution.
- 2-channel amplifier with state-of-the-art Class D concept, which combines outstanding sound quality with maximum efficiency
- Bridgeable output channels for flexible system configurations and maximum power output
- High output power of up to 1000 W RMS bridged at 4 Ω – ideal for driving powerful subwoofers
- Innovative ACP (Amplifier Control Panel) for intuitive configuration of various amplifier functions, such as:
- Automatic and manual gain adjustment
Input mode
Input reference configuration
- Precise gain adjustment for optimal signal processing – selectable automatic or manual mode:
- Auto Gain Ranging (AGR) automatically detects input sensitivity and sets the gain for maximum sound quality
- Manual gain adjustment from 0.5 to 8 Volts in 0.5 V steps for precise adaptation to individual system requirements
- V-AMP Link – specially optimized input for connecting a HELIX V Series amplifier for powerful signal amplification in subwoofer or high-power speaker applications
- Designed for HELIX DSP products – DirectDSP input perfectly tuned for maximum signal quality and performance
- MSM (Mono / Stereo Mode) – allows operation as a powerful mono amplifier for subwoofers or as a stereo amplifier for powerful speaker setups
- Stabilized Output Power (SOP) technology for consistent and reliable output performance, regardless of input voltage
- Intelligent power management ensures perfect voltage stability across all modern vehicle platforms
- Start-Stop capable power supply with extended input voltage range up to 18 V – ideal for modern EV vehicles
- Auto Remote switch for amplifier activation without the need for an external remote signal
- Compact design with low heat dissipation thanks to extraordinary efficiency
Power meets audiophile performance
With a high signal-to-noise ratio of > 109 dB, an extremely low total harmonic distortion of < 0.004 % THD+N, and a high damping factor, the V TWO effortlessly meets even the most demanding sonic expectations. Its bridgeable speaker outputs ensure maximum output power exactly where it’s needed. This makes the V TWO the ideal choice for anyone seeking uncompromising sound performance combined with exceptional versatility.
Stereo performance for versatile speaker applications
In fullrange stereo operation, the V TWO delivers 2 x 200 Watts RMS at 4 Ohms and 2 x 400 Watts RMS at 2 Ohms – more than enough power to drive even demanding midbass speakers or hybrid subwoofers like the COMPOSE i5 S200FM with authority.
In addition to its powerful output, it also impresses with tonal precision: the wide frequency response and audiophile-grade characteristics ensure that even the finest details are reproduced with accuracy and uncolored.
Mono bridged operation for output-focused subwoofer applications
In bridged mode, the V TWO delivers up to 800 Watts RMS at 4 Ohms – more than enough to drive even high-performance subwoofers with full dynamics and control. Powerful DVC2 subwoofers (2 x 2 Ohms) like those from the HELIX IMPACT Q series or two series-wired SVC2 subwoofers (1 x 2 Ohms) from the HELIX IMPACT K series, benefit from the high efficiency and outstanding sound quality of this configuration. Thanks to the integrated mono mode, a single input signal is sufficient for full operation – the perfect setup for use with DSPs that already provide a summed subwoofer output.
