Phoenix Gold ZQ15001 Sub Amp Monoblock Subwoofer Class D High End Amplifier

ZQ15001 Monoblock Class D High End Amplifier

The ZQ15001 is a powerful Monoblock Class D amplifier offering up to 1500W of power. This unit is perfect for growing installations over time, offering enough power to start an install and continue giving a smooth power supply as a system is upgraded and updated. The ZQ15001 is a strong durable unit in a attractive compact casing making it usable in a variety of applications.

Key Features

• Pure Class D Technology

• Power Ratings (RMS)

• 650W x 1 @ 4Ohm

• 1000W x 1 @2Ohm

• 1500W x 1 @ 1Ohm

• Frequency Response: 5Hz 250Hz

• Signal to Noise Ratio: >80dB

• Low Pass Filter: 40Hz 250Hz

• Subsonic Filter: 5Hz 50Hz

• Bass Boost: @ 45Hz 0 to +18dB

• Phase Control: 0-180

• Input Impedance: 20K Ohm

• Supply Voltage: 11 – 15V

• Dimensions (LxWxH): 280 x 200 x 56mm

The ZQ15001 is a powerful Monoblock Class D amplifier offering up to 1500W of power. This unit is perfect for growing installations over time, offering enough power to start an install and continue giving a smooth power supply as a system is upgraded and updated. The ZQ15001 is a strong durable unit in a attractive compact casing making it usable in a variety of applications.

The ZQ Series of amplifiers feature award winning technology that not only offers a natural uncompromised sound but also a design that represents Phoenix Golds past, present, and future all in one. Highly sought after by PG enthusiasts and audiophiles alike, the ZQ Series is a rebirth of PGs original core values offering premium high-end technology that brings the purest audio sound to the masses.

The Gold Treated PCBs of the ZQ15001 feature a unique two layered, gold immersion treatment along with 24K gold plated terminals offering superior connectivity. The dual power supply has been optimised to proficiently feed the amp and only the best Nichicon (Japan) & Wima (Germany) capacitors are used to provide the best possible uninterrupted power supply.

A high level of engineering has gone into making these amps with low EMI emissions to not interfere with the advanced electronics or FM signal.
