Helix V Twelve DSP 12 MK2 Channel Amplifier with 14 Channel DSP 75w RMS 64 Bit

HELIX V TWELVE DSP MK2

12 Channel amplifier with integrated 14-channel DSP 8 x 75 / 150 Watts @ 4 Ohms

The new king of multitools

The V TWELVE DSP MK2 is the new problem solver when it comes to upgrading premium sound systems in today's vehicles. Like its predecessor, it combines 12 highlevel inputs, 6 RCA inputs, 14 DSP channels and 12 output stages with up to 160 RMS at 2 Ohms in an ultra-compact housing that has the footprint of just two envelopes.

Features

• Up to 160 W RMS output power per channel into 2 Ω
• “Pure Class GD” concept for outstanding sound quality combined with best possible efficiency
• Extremely powerful 64 Bit “fixed point” Audio DSP
• A/D and D/A signal converters from BurrBrown
• ACO – Advanced 32 Bit CoProcessor platform for system and DSP features like:
• ISA (Input Signal Analyzer) and InputEQ for easy analysis and compensation of input signals
• SFX sound effects – Augmented Bass Processing, StageXpander, RealCenter & Co.
• 10 internal memory locations for sound setups
• High power 12-channel highlevel input with up to 32 V RMS input sensitivity and ADEP.3 circuit
• Two processed RCA / Cinch outputs
• 1:1 IOR (Input / Output Routing) – same number of highlevel inputs and amplifier outputs
• VCP (Virtual Channel Processing) allows even more flexible configuration for highly complex sound systems
• Compact, future-proof SCP (Smart Control Port) for connecting remote controls and accessories
• HEC slot for system add-ons like Bluetooth® HD Audio Streaming, High Resolution Audio Streaming via USB etc.
• Automatic Remote switch
• Start-Stop capability down to 6 Volt supply voltage
• Compact design with low heat dissipation thanks to extraordinary efficiency

Virtual Channel Processing – this is how signal routing works today

The adaptation to modern OE sound systems via an increasing number of inputs has a significant impact on the complexity of the signal routing inside the amplifier. Especially when several input signals are mixed together and then split again into multi-way systems, conventional routing concepts quickly reach their limits. Audiotec Fischer's new multi-stage "Virtual Channel Processing", in conjunction with the recognized user-friendly DSP PC-Tool software makes it easy to realize even highly complex system configurations. Besides, it allows to freely assign our proprietary FX sound features such as "RealCenter" or "Augmented Bass Processing". But thanks to its enormous number of channels, the V TWELVE DSP MK2 is also a prime example for applications in which a 1-to-1 routing (IOR) makes sense.

Rapid processing power – thanks to ACO

Such a huge number of channels not only requires a rapid processing power in the signal path – Audiotec Fischer's proprietary 32 Bit ACO platform takes over all control tasks and thus ensures exceptional speed especially for data communication with our DSP PC-Tool software, but also for lightning-fast switching between up to ten possible sound setups. The fantastic sound effects associated with the ACO platform such as Augmented Bass Processing, StageXpander or RealCenter are just as natural with the V TWELVE DSP MK2 as a 12-channel input EQ including our Input Signal Analyzer (ISA) for easy analysis and compensation of the input signals from OE radios.

Perfect sound without compromises

The sound performance of the new HELIX V TWELVE DSP MK2 is as impressive as its range of features. The highly efficient Class GD technology and excellent A/D and D/A converters from BurrBrown ensure optimal sound performance, best possible signal-to-noise ratio and lowest distortion. Thus, despite its extremely high flexibility and super compact design, the V TWELVE DSP MK2 is an sound masterpiece that does not need to hide from the absolute top class at all.
